BIOS Firmware vs UEFI: The Ultimate Guide

Updated on:
Updated by: Panseih Gharib

Ever wondered what brings your computer to life when you press the power button? The answer lies in the mysterious world of firmware, specifically the BIOS firmware or UEFI. These fundamental components are the unsung heroes that bridge the gap between your hardware and operating system.

But what exactly are BIOS and UEFI, and how do they differ? Which one is better? Join us as we delve into the intricacies of these two firmware titans, uncovering their roles, capabilities, and the impact they have on your PC’s performance and security.

Whether you’re a seasoned tech enthusiast or a curious newcomer, this guide will equip you with the knowledge to make informed decisions about your PC’s firmware.

The BIOS (Basic Input/Output System) is a fundamental piece of software embedded directly into your motherboard. It acts as the computer’s initial boot-up program, performing essential tasks like:

  • Power-On Self-Test (POST): Checking the hardware for any issues before the operating system loads.
  • Hardware Configuration: Managing and configuring basic hardware components.
  • Boot Loader: Initiating the process of loading the operating system.

To access and modify BIOS settings, you’ll typically need to press a key (like Delete, F2, or F10) immediately after turning on your computer. The exact key is usually displayed briefly on the boot screen.

Inside the BIOS Setup, you’ll see different menus and options to configure various settings:

  • Boot options (boot order, boot from USB/DVD/network etc.)
  • CPU settings (virtualisation support, overclocking etc.)
  • Memory/RAM settings (clock speed, timing controls)
  • Storage settings (drive configurations, RAID setup)
  • Power management (sleep modes, wake timers)
  • Security (administrator/user passwords, TPM settings)
  • System date, time and regional settings

The BIOS stores its configuration settings in a small, battery-powered chip called the CMOS. This chip retains the BIOS settings even when the computer is powered off.

Whenever you make adjustments within the BIOS Setup utility, the new settings are saved to the CMOS memory. Importantly, removing the CMOS battery or clearing the CMOS settings will erase all stored information and restore the BIOS to its default configuration.

If you’ve made BIOS changes that are causing issues or simply want to restore default settings, you can reset the BIOS/CMOS. There are several methods to achieve this:

  • CMOS Battery Removal: Carefully remove the CMOS battery from the motherboard for a short period (usually 30 seconds to a few minutes) to clear the stored BIOS settings.
  • CMOS Reset Jumper: Some motherboards have a dedicated CMOS reset jumper. Refer to your motherboard manual for specific instructions on how to use it.
  • Load BIOS Defaults: Access the BIOS setup utility and look for an option to load default settings. This method varies between motherboard manufacturers.

Always consult your motherboard manual for precise instructions on resetting the BIOS/CMOS. Incorrect procedures could potentially damage your system.

BIOS Firmware vs UEFI: The Ultimate Guide

BIOS beep codes are audible signals that indicate hardware issues during the Power-On Self-Test (POST). While specific beep patterns vary between motherboard manufacturers, some common ones include:

  • One short beep: Typically indicates a successful POST with no detected errors.
  • Two short beeps: Often signal a CMOS battery failure.
  • Continuous long beeps: Commonly associated with memory (RAM) problems.

However, it’s essential to consult your motherboard’s manual for accurate interpretations. The absence of any beeps might suggest a more severe issue with the motherboard, CPU, or power supply.

Most modern BIOS and UEFI firmware include security features to prevent unauthorized access:

  • Administrator/User Passwords: Restrict access to BIOS Setup and booting
  • Drive Encryption: Enable full disk encryption of storage drives
  • Secure Boot: Ensure only signed boot loaders/drivers load (UEFI)
  • Execute Disable Bit: Prevent certain malware/virus code execution

However, default BIOS/firmware can still be vulnerable to attacks like BIOS rootkits or bootkits. Keeping firmware updated with the latest security patches is essential.

Updating BIOS Firmware: Why, When and How

Motherboard manufacturers periodically release updates to the BIOS firmware/software itself. These updates may:

  • Add support for new CPU models or other hardware
  • Fix bugs or security vulnerabilities
  • Improve existing functionality and features

BIOS updates should be installed carefully, following the manufacturer’s instructions. An incomplete or interrupted update can potentially render the system unbootable.

Replacing a Damaged BIOS Chip: A Delicate Procedure

BIOS Firmware vs UEFI: The Ultimate Guide

In rare cases of a severely corrupted BIOS or physical chip damage, the BIOS chip itself may need replacement on the motherboard. This has to be done carefully:

  1. Identify and purchase the exact BIOS chip model from the motherboard maker
  2. Take anti-static precautions to avoid electrostatic discharge
  3. Locate and remove the old BIOS chip without bending the pins
  4. Insert new BIOS chip oriented correctly
  5. Configure BIOS settings after replacing the chip

Only experienced technicians should attempt BIOS chip replacement as it’s a delicate process. An alternative is to replace the entire motherboard instead.

Anatomy of The Boot Process: A Step-by-Step Breakdown

  1. Power On Self Test (POST): The BIOS initializes and performs a series of tests on the system’s hardware components like CPU, RAM, storage devices, etc.
  2. BIOS Checks Boot Devices: Based on the set boot order, the BIOS looks for bootable devices like a hard disk, USB drive, optical disc, etc.
  3. Master Boot Record (MBR) is Read: The first section of the bootable device contains the Master Boot Record, which has a small program that starts the actual operating system bootloader.
  4. Boot Loader Loads Operating System: The boot loader program (e.g. Windows Boot Manager, GRUB) takes over and loads the full operating system kernel into memory.
  5. Operating System Initialisation: The operating system completes its startup procedures, loads drivers and finally presents the user login screen.

Common Boot Loaders Used by Different Operating Systems

Different operating systems use their boot loaders:

  • Windows: Windows Boot Manager
  • Linux: GRUB, LILO
  • macOS: Apple Boot Loader
  • ChromeOS: Chrome OS Boot Loader

These boot loaders are responsible for loading the respective operating system kernel from the boot device.

UEFI: The Modern Successor to Legacy BIOS

UEFI (Unified Extensible Firmware Interface) is a newer specification aiming to eventually replace the traditional BIOS firmware. Here are some of the key differences:

BIOS vs UEFI:

FeatureBIOSUEFI
User InterfaceText-based menusGUI with mouse support
Boot SpeedRelatively slowerFaster boot times
Boot Device SupportLimited to MBR partitionsSupports GUID Partition Table (GPT)
Hardware InitialisationLimited, no multi-threadingParallel initialisation of components
Hardware SupportLimited to 16/32-bit systemsOptimised for 32/64-bit systems
OS SupportLimited native supportBetter OS integration
Security FeaturesBasic passwordsSecure boot, network stack
UEFI represents a more modern, scalable solution designed for today’s advanced computing hardware and operating systems.

Inside the UEFI System Setup: Navigation and Configuration

Similar to the older BIOS Setup, UEFI systems also have a setup/configuration utility accessed by pressing a specific key during boot. However, UEFI setups offer a graphical user interface with mouse support.

Common UEFI settings include:

  • Boot options and order
  • Device configurations (USB, Thunderbolt etc.)
  • CPU and memory overclocking
  • Secure boot and operating system preferences
  • System date, time and language settings

Secure Boot: UEFI’s Built-in Defense Against Malware

One of UEFI’s key security advantages is Secure Boot. It ensures that only authorised/signed operating system loaders and drivers can be loaded during the boot process. This helps prevent rootkits and other malware from compromising the system during startup.

Updating UEFI Firmware: Keeping Your System Secure and Compatible

UEFI firmware also requires periodic updates from the system manufacturer. These updates may include:

  • Support for newer CPU/chipset models
  • Bug fixes and security patches
  • UEFI feature enhancements

The update process typically involves downloading the update file/utility from the manufacturer’s website and running it to flash the new UEFI firmware version.

Understanding GPT Partitions: UEFI’s Preferred Disk Format

Unlike the legacy MBR (Master Boot Record) partitioning scheme, UEFI uses the newer GUID Partition Table (GPT) format. GPT offers advantages like:

  • Support for over four primary partitions
  • Up to 9.4 ZB maximum disk size support
  • Redundant partition tables for recovery
  • Partition naming in Unicode

For GPT disks, the UEFI firmware looks for an EFI System Partition (ESP), which contains boot loaders and drivers that are required for startup.

Legacy vs UEFI Boot Mode: Choosing the Right Option

On systems that support both BIOS and UEFI, you may have an option to choose the boot mode:

  • BIOS/Legacy Mode: Boot uses the traditional BIOS method (MBR partitions)
  • UEFI Mode: Boot process uses the newer UEFI firmware (GPT partitions)

Most modern operating systems, such as Windows 10/11 and recent Linux distributions, support both BIOS and UEFI boot modes natively.

Dual BIOS/UEFI Motherboards: Redundancy for Critical Systems

Some systems ship with dual BIOS/UEFI chips on the motherboard to provide redundancy. If one BIOS/UEFI gets corrupted, the other can take over on the next boot.

In these setups, the backup BIOS/UEFI may be initiated by:

  • Manually switching a backup BIOS physical switch/jumper
  • Automatic failover if main BIOS/UEFI is corrupt
  • Performing a special keystroke during POST

Refer to your motherboard’s documentation for details on using the dual BIOS/UEFI functionality.

Unleashing UEFI’s Network Boot Capabilities

UEFI firmware includes a TCP/IP network stack with the ability to boot from various network sources like:

  • Pre-boot Execution Environment (PXE) for network boot
  • HTTP/FTP boot to load images over the internet
  • iSCSI remote booting from storage area networks
  • Load operating systems from a Windows Deployment Server

This network functionality in UEFI allows more flexible and remote OS deployment options in enterprise environments.

Emulating BIOS or UEFI for Compatibility: Bridging the Gap

In some scenarios, you may need to run an older BIOS-based operating system on newer UEFI systems. Solutions include:

  • Emulation Mode: Enable a firmware setting to emulate a BIOS environment for MBR booting
  • Use a conversion tool to create a BIOS boot partition
  • Run the legacy OS in a virtual machine with BIOS emulation

Conversely, some UEFI firmware has a “BIOS boot” mode that allows booting UEFI-based operating systems on legacy BIOS systems.

Whether you use a legacy BIOS or a modern UEFI system, understanding these firmware fundamentals empowers you with the knowledge to configure system settings, update firmware, secure boot process, troubleshoot issues and maximise your computing hardware’s capabilities.

FAQ

Do I need to update BIOS/UEFI firmware regularly?

It’s recommended that you update your system to the latest stable BIOS/UEFI versions provided by your system manufacturer to get hardware compatibility updates and security fixes.

How do I check what BIOS/UEFI version I’m running?

The BIOS/UEFI version is displayed during boot-up or can be viewed via the BIOS/UEFI setup utility.

Can I install Windows/Linux on a BIOS or UEFI system?

Modern Windows and Linux versions support both BIOS and UEFI boot modes natively. The installation routine detects and follows the appropriate mode.

What if I interrupted a BIOS/UEFI update process?

An incomplete BIOS/UEFI update can leave the system unbootable. Follow your manufacturer’s recovery instructions, which may involve using a backup BIOS/UEFI or removable media.

My BIOS/UEFI has an option for \u0022BIOS Legacy Mode\u0022, what does it mean?

This setting emulates a traditional BIOS environment on UEFI systems to allow the booting of older operating systems that don’t support UEFI natively.

Should I be worried about BIOS/UEFI security vulnerabilities?

Like any software, BIOS/UEFI can have vulnerabilities that malware could exploit. Keeping firmware updated with security patches released by manufacturers is recommended.
